SV 6.16.5p, Dehn DCOR L 2P 275

Manufacturer Code: H115120
89,59 € without VAT 108,41 € with VAT
SV 6.16.5p, Dehn DCOR L 2P 275
Rated cross-section [mm²] 16
Rated current [A] 76
Rated voltage Ui [V] 1 000
Rated impulse withstand voltage Uimp [V] 4 000
Clamped conductor range [mm²] (solid conductor) 1,5 - 16
Composition of the terminal block (Main terminal) 6 x RSA 16 A
Composition of the terminal block (Main terminal for PE conductors) 2 x RSA PE 16 A
Composition of the terminal block (Fuse terminal) 1 x RSP 4
Composition of the terminal block (Overvoltage protection) 1 x DCOR L 2P 275
Tightening torque [Nm] terminal blocks / fuse clamp 2 / 0,5
Tools terminal blocks / fuse clamp PH2 / PH0
Pollution degree 2
IP code 20
Operating temperature [°C] -40 - +55
Testing ČSN EN 60947-7-1; ČSN EN 60947-7-2; ČSN EN 60947-7-3

Dimensions

A [mm] 60
B [mm] 64
C [mm] 167
C1 [mm] 40
L [mm] 250
