Terminal block RSA 70 A yellow
Manufacturer Code: A581261
7,56 € without VAT 9,14 € with VAT
Terminal block RSA 70 A yellow
Rated cross-section [mm²] | 70 |
Rated current [A] | 192 |
Short-time withstand current [A] | 8400 |
Insulation voltage Ui [V] | 1000 |
Impulse voltage U (Imp) [V] | 4000 |
Tightening torque [Nm] | 6 |
Tools | Inbus number 6 |
Assembly method (on DIN rail) | TH 35 |
Pollution degree | 2 |
IP code | 10 |
Operating temperature [°C] | -20 - +105 |
Number of clamping points per level | 2 |
Number of levels | 1 |
End cover plate required | NO |
Testing | ČSN EN 60947-7-1 |
Dimensions [mm] (width / height / length) | 24 / 85 / 70 |
Weight [g] | 137 |
Packing [pcs] | 10 |
Clamping screw | M 8 x 20 |
Solid conductor [mm²] | 10 - 16 |
Stranded conductor [mm²] | 25 - 95 |
Finely stranded conductor [mm²] | 16 - 70 |
2 x Solid conductor, stranded, finely stranded [mm²] | 10 - 16 |
Maximum conductor connection cross-section, fi nely stranded with wire-end ferrules with plastic collar [mm²] | 70 |
Stripping length [mm] | 18 |
Insulating body | Polyamide PA 6, flammability V0 halogen free |
Electric conductive part | Brass (galvanic surfaced) |
Fixing part | Thermally treated steel (galvanic surfaced) |
