Terminal block RSA 70 A white
Manufacturer Code: A181111
8,01 € without VAT 9,70 € with VAT
Terminal block RSA 70 A white
| Rated cross-section [mm²] | 70 |
| Connection capacity [mm²] | 10 ÷ 95 |
| Rated current [A] | 192 |
| Rated current ATEX [A] | 165 |
| Short-time withstand current [A] | 8400 |
| Insulation voltage Ui [V] | 1000 V |
| Voltage ATEX [V] | 1000 |
| Impulse voltage U (Imp) [V] | 4000 |
| Tightening torque [Nm] | 6 |
| Tools | Inbus č. 6 |
| Assembly method (on DIN rail) | TH 35 |
| Pollution degree | 2 |
| IP code | 10 |
| Operating temperature [°C] | -20 ÷ +105 |
| Number of clamping points per level | 2 |
| Number of levels | 1 |
| End cover plate required | NO |
| Testing | IEC 60947-7-1 |
| ATEX approval | Ex II 2G Ex eb IIC Gb /Ex I M2 Ex eb I Mb |
| Dimensions [mm] (width / height / length) | 24 / 85 / 70 |
| Weight [g] | 137 |
| Packing [pcs] | 10 |
| Clamping screw | M 8 x 20 |
| Solid conductor [mm²] | 10 ÷ 16 |
| Stranded conductor [mm²] | 25 ÷ 95 |
| Finely stranded conductor [mm²] | 16 ÷ 70 |
| 2 x Solid conductor, stranded, finely stranded [mm²] | 10 ÷ 16 |
| Maximum conductor connection cross-section, fi nely stranded with wire-end ferrules with plastic collar [mm²] | 70 |
| Stripping length [mm] | 18 |
| Insulating body | Polyamide PA 6, flammability V0 halogen free |
| Electric conductive part | Brass (galvanic surfaced) |
| Fixing part | Thermally treated steel (galvanic surfaced) |
